Installation and Setting to Work Parameters
30 The SharpEye
TM
Transceiver contains a number of operational settings that are set up
during system installation and setting to work. These operational settings are:
(1) Rotation Rate. The transceiver supports 2 nominal antenna rotation rates, 22 rpm
and 44 rpm. System behaviour and performance varies depending upon which
rotation rate is selected as the system parameters are adjusted for the different
rotation rates.
(2) Operating Frequency. The transceiver contains 14 pre-set transmission
frequencies within the operating frequency band. The frequency used for a
particular system is set during system installation and setting to work. The centre
frequencies of each RF band are:
(a)
9.22GHz ±15 kHz.
(b)
9.24GHz ±15 kHz.
(c)
9.26GHz ±15 kHz.
(d)
9.28GHz ±15 kHz.
(e)
9.30GHz ±15 kHz.
(f)
9.32GHz ±15 kHz.
(g)
9.34GHz ±15 kHz.
(h)
9.36GHz ±15 kHz.
(i)
9.38GHz ±15 kHz.
(j)
9.40GHz ±15 kHz.
(k)
9.42GHz ±15 kHz.
(l)
9.44GHz ±15 kHz.
(m)
9.46GHz ±15 kHz.
(n)
9.48GHz ±15 kHz.
(3) Transmit Inhibit Sector. The transceiver provides one blanking sector that is
configured via the display system. The radar does not transmit RF energy within
the blanking sector.
KH1264
Chap ter 3
Page 3.10 Is sue 2
