User's Manual
Table Of Contents
- KH1264 ISSUE 1
- CHAPTER 1
- CHAPTER 2
- CHAPTER 3
- CONTENTS
- ILLUSTRATIONS
- Figure 1 - Transceiver (DTX-A3): Module Locations 34
- Figure 2 - Drive Control Unit (GTX-A24): Module Locations 35
- Figure 3 X-band Upmast Transceiver (DTX-A3): Functional Diagram Figure 3 38
- Figure 4 X-band Upmast Transceiver (DTX-A3): Interconnection Diagram Figure 4 39
- Figure 5 - Drive Control Unit (GTX-A24): Block Diagram 319
- CHAPTER 4
- CONTENTS
- TABLES
- ILLUSTRATIONS
- Figure 1 - Transceiver (DTX-A3): Installation Dimensions 49
- Figure 2 - Transceiver (DTX-A3): Mast Mounting 410
- Figure 3 - Transceiver (DTX-A3): Fitting Kit 411
- Figure 4 - Suggested Antenna Lifting Arrangement 412
- Figure 5 - Drive Control Unit (GTX-A24): Installation Dimensions 413
- Figure 6 - Mains Isolator: Installation Dimensions 414
- Figure 7 - Transceiver (DTX-A3): Cableform Routing 419
- Figure 8 - Drive Control Unit (GTX-A24): Cableform Routing 420
- Figure 9 - Cable Gland: Assembly 421
- Figure 10 - Transceiver (DTX-A3): External Connections 423
- CHAPTER 5
- CHAPTER 6
- CONTENTS
- INTRODUCTION 63
- PLANNED MAINTENANCE 63
- DIAGNOSTIC MAINTENANCE 64
- CORRECTIVE MAINTENANCE 611
- TRANSCEIVER (DTX-A3) 612
- Access 612
- Removal of Rotating Joint (45-750-0034-001) 612
- Replacement of Rotating Joint (45-750-0034-001) 613
- Removal of Gearbox and Motor (55-100-0273-001) 613
- Replacement of Gearbox and Motor (55-100-0273-001) 613
- Removal of Azimuth Encoder (GTX-A188) 613
- Replacement of Azimuth Encoder (GTX-A188) 613
- Transceiver (DTX-A115) - Removal 614
- Transceiver (DTX-A115) - Replacement 614
- Power Supply (45-690-0062-002) and PSU Sense PCB (DTX-A121) - Removal 615
- Power Supply (45-690-0062-002) and PSU Sense PCB (DTX-A121) - Replacement 615
- CAN Adapter PCB (NNR-A981) - Removal 615
- CAN Adapter PCB (NNR-A981) - Replacement 615
- SharpEye Azimuth Interface PCB (DTX-A151) - Removal 616
- SharpEye Azimuth Interface PCB (DTX-A151) - Replacement 616
- DRIVE CONTROL UNIT (GTX-A24) 618
- CHECKS AFTER UNIT REPLACEMENT 620
- TRANSCEIVER (DTX-A3) 612
- ILLUSTRATIONS
- CONTENTS
- CHAPTER 7
- INSTALLATION AND SERVICE REPORTS
Sig nal Pro ces sor
Digital Phase Sensitive Detector
Digital Pulse Compression
Maximum instrumented range: 48 nm
Compressed pulse lengths: 0.1 ms or 0.2 ms
Antenna
Antenna Type: End fed slotted array
Polarisation: Horizontal
Turning Circle: 2.6 m
Horizontal beamwidth: 0.95°
Vertical beamwidth: 26°
Sidelobes: £ -30 dB, 1st sidelobe £ -26 dB typical
>10° sidelobes £ -33 dB typical
Antenna gain: 30 dB
Frequency range: 9.22 GHz to 9.48 GHz (centre frequencies)
Turn ing Mech a nism
Azimuth Data: 4096 pulses per antenna revolution
Heading Data: 1 pulse per revolution
Antenna rotation rates: 22 or 44 RPM for optimum update rate
Op er at ing Tem per a ture Ranges
Ambient Range Operational: -25°C to +55°C
Storage: -25°C to +70°C
Humidity 95% at +40°C
In put Power
Input Power Single Phase: 110 V/220 V 50/60 Hz AC input
(Transceiver) 440 VA max
Input Power Single Phase: 220 V 50/60 Hz AC input
(Drive Control Unit): (or 110 V via a transformer)
2200 VA max
KH1262
Chap ter 2
Page 2.4 Is sue 2
