CHAPTER 2
SPECIFICATION
TECH NI CAL SPEC I FI CA TIONS
1 The technical specifications for the SharpEye
TM
X-band Upmast Transceiver is as
follows:
Fea tures
Range resolution: 40 m
Dynamic range: ³ 100 dB (including Sensitivity Time Constant (STC))
ensures simultaneous detection of large and small
targets
Radar control: CANbus
System Type: Fully coherent
Trans mit ter
Frequency: 1 of 14 frequencies, each 20 MHz wide,
selectable in the band 9.22 GHz to 9.48 GHz
Type: Solid state power amplifier
RF Peak output power: 170 W minimum
Pulse width: 0.1 ms to 40 ms
Re ceiver
Type: Single channel, linear
Noise figure: 5 dB
Dynamic range: 65 dB at Analogue-to-Digital output, excluding STC
96 dB at Analogue-to-Digital output, with STC
Output: Analogue radar video and sync
KH1264
Chap ter 2
Is sue 2 Page 2.3
