Product Manual

MATGUIDE EXTENSION KIT 75cm (30”)
Consists of an extended Matguide Slideway 1 and two base extension arms for controlling a cut up to 75cm (30”) away
from the Matguide. Increases the effective base width to 100cm (39”).
FITTING
Remove the Matguide Slideway
1 and the Matguide T-Bar 2. Clip the Extended Matguide Slideway and Base
Extensions to the machine, then refit the Matguide T-Bar.
1 Refer to the section 'The Alignment of the Matguide T-Bar' but make any necessary adjustment using the two nuts
under the mat guide slideway as shown.
NOTE: Calibration of the Matguide Limit Stop may be necessary.
USE
Use the Matguide in the same way as normal ensuring that the left edge of the mat board is in contact with the T-Bar at
all times when cutting.
Matguide Extension Kit 75cm (30")
