User Manual

Signal Input, Direction Switch, and Main Speed Potentiometer connections.
Sets the drive for operation with a voltage or current input signal. Sets the Run/Fault Relay Output Contacts for normally open or closed operation.
All jumpers are shown in factory set positions.
Run/Fault Relay Output Contacts connection.
Sets the operation of the Run/Fault Relay to Run or Fault.
Used to connect the Signal Isolator and Run/Fault Relay to the KBVF.
Sets the drive for operation with the optional Dynamic Brake Module.
MAXOFFSET
NDBM
J5
DBM
CON1
RUN
J4
FAULT
Power on LED. Maximum Speed adjustment trimpot.
Signal Offset adjustment trimpot.
OV
PWR
TB1
-5V+5V FWD REV COM1SIG1
VOLTCUR
TB2
K1 K2
NC
J2J1
NO
6
FIGURE 3 – SIVFR CONTROL LAYOUT
(SIVFR is Built-In on Models KBVF-45, 48 and Optional on Models KBVF-27, 29)
