Electrical Installation
Remark: The cables must be protected against mechanical damage.
Optimal protection offers a protective cable guard. Cables must be fixed
with cable strap in such a way that the maximum protection against
mechanical damage is provided.
Connection Cable (Ethernet + Power Supply)
Part number Cable length
34015780100 33 feet (10m)
34015780140 46 feet (14m)
34015780180 59 feet (18m)
34015780220 72 feet (22m)
34015780260 85 feet (26m)
34015780300 98 feet (30m)
34015780500 164 feet (50m)
Other lengths are available on request.
Recommendation for
cabling
Table 9
Available lengths of
Connection Cable
Figure 6
Connection Cable
(Ethernet + Power Supply)
Figure 7
Connector pin assignment
Connection Cable
(Ethernet + Power Supply)
to protection unit TCM/TIM
IPC
Shield
24 or 48V DC
MTX
IN
