Technical Manual | WAVE Transceiver with precise localization capability MTX-9450 and TRX-9450 Page 17 of 26
1000005502-THb-03
Installation
The described mounting applies to all transceivers specified in this
documentation.
Mounting position and height
• The antenna should point towards the direction of traffic flow.
• The mounting device offers the possibility to adapt to different
environments, for example mounting under a ceiling is possible.
Warning: When mounting the bracket to a bridge, a gantry or a wall the
appropriate safety regulations must be followed.
Mounting plate for MTX-9450 and TRX-9450
The mounting plate is part of the transceiver and must not be removed.
Figure 4
Mounting plate for MTX-9450 and
TRX-9450
Ground
point
Mounting
Plate
