Page 16 of 26 Technical Manual | WAVE Transceiver with precise localization capability MTX-9450 and TRX-9450
1000005502-THb-03
Module
Description
Kapsch
Part No.
TCM-0902 Module for up to two TIM modules 34019410000
TIM-5310* Module for Line application
(48V / 2.5A fuse, type slow blowing)
34026560000
* Quantity: One (1) TIM module per TRX
For more detailed information see the technical manual of the transient
protection unit (Doc. No. 1000002917 or 1000003873).
The power supply must be mounted in the roadside cabinet. The power
supply for the transceiver has to fulfill the requirements for a SELV-circuit
(S
afety Extra Low Voltage). The recommended supply voltage is 48V DC. A
UL compliant industrial power supply must be used.
Recommended power supplies see Table 5 on page 14.
Table 8
Available TCM and TIM modules
Power supply
