User's Manual

Page 14 of 26 Technical Manual | WAVE Transceiver with precise localization capability MTX-9450 and TRX-9450
1000005502-THb-03
See applications notes.
Max. Length 260feet (80m)
See chapter “Connection Cable (Ethernet + Power Supply)” on page 19.
The transient protection unit consists of the two modules.
Module Description Kapsch
Part No.
TCM-0902 Module holder for up to two TIM modules 34019410000
TCM-0904 Module holder for up to four TIM modules 34018320000
TIM-5310* Overvoltage Protection Unit
(48V / 2.5A fuse, type slow blowing)
34026560000
* Quantity: 1 TIM module per transceiver
For more detailed information see the technical manual of the transient
protection unit (Doc. No. 1000002917 or 1000003873).
Module Description Kapsch
Part No.
PPS-RS422-MUX-2 Service and Synchronization
Unit up to 2 TRX
34026530010
PPS-RS422-MUX-8 Service and Synchronization
Unit up to 8 TRX
34026530000
The power supply must be mounted inside the roadside cabinet. The power
supply for the transceivers has to fulfill the requirements for a SELV-circuit
(S
afety Extra Low Voltage). The supply voltage has to be 24 or 48V DC. A
UL compliant industrial power supply must be used.
Manufacturer Type Description Kapsch
Part No.
TRACO TSL240-124 24V DC / 10A / 240W 1000000904
TRACO TSL240-148 48V DC / 5A / 240W 1000000160
The Transceiver controller must be mounted inside the roadside cabinet.
Type Description Kapsch
Part No.
TRC-1040-IPC Transceiver Controller for WAVE
For more detailed information see the technical manual of the transceiver
controller.
Installation
Connection Cable
Transient Protection Unit
Table 3
Available TCM and TIM modules
Service and
Synchronization Unit
Table 4
Available PPS-RS422-MUX
modules
Power supply
Table 5
Recommended power supplies
Transceiver Controller
Table 6
Available Transceiver Controllers
TRC-1040-IPC
