Product Specifications
Transceivers MTX-9450 and TRX-9450
Dimensions [LxWxH] 16.5 in x 7.9 in x 3.4 in
(420mm x 200mm x 86mm)
Weight without bracket <16 pounds (<7 kg)
Material of housing Alloy die casting, Radom: Polycarbonate
Wind load 70 km/h (43.5 mph) – 34.5 N
120 km/h (74,6 mph) – 100 N
140 km/h (87.0 mph) – 137.5 N
160 km/h (99.4 mph) – 180 N
Interface Specification
Rated Input Voltage Nom. 24V DC up to 48V DC
Input Voltage Range Min: 21.6V DC (=24V – 10%) permanent
Max: 52.8V DC (=48V + 10%) permanent
Protection The Transceiver is internally protected against
reverse polarity of the input voltage and internally
fused with 3A (type slow blowing). The fuse cannot
be changed by the user.
Power consumption
at maximum transmit
power
MTX 24W typical
TRX 24W typical
Radio 1
Frequency range 5.850GHz - 5.920GHz
Channels Channels: 172,174,176,178,180,182,184
Data Rates 3MBit/s – 27MBit/s
Antenna Polarization Right hand circular
Radiated power
External Antenna N-
Connector (MTX only)
≤ 33dBm EIRP
≤20dBm conducted
Radio 2
Frequency range 5.850GHz - 5.920GHz
Channels Channels: 172,174,176,178,180,182,184
Data Rates 3MBit/s – 27MBit/s
Antenna Polarization
Radiated power
External Antenna N-
Connector (MTX only)
Right hand circular
≤ 20dBm EIRP
≤ 10dBm conducted
Mechanical characteristics
Electrical characteristics
and conditions
RF Interfaces
