Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Switchover on Serial
Link Down
From the General tab
on the Configuration
page:
With Serial
communications
enabled, select the
Switchover on Serial
Link Down check box.
user with
Advanced
User
permission
SOSERL
0
0-1
Disabled: switchover does
not occur when the Serial
link is down.
Enabled: Enable means
switch-over to secondary
side if the reader
determines a serial link to
the lane controller is
down. Has no meaning on
secondary side.
NOTE: If
enabled, you
MUST also
disable all
unused COM
ports (see
SERIAL tab) as
well as unused
LC destinations
(see LC tab).
Switchover on
Ethernet LC Link
Down
From the General tab
on the Configuration
page:
With Ethernet LC
communications
enabled, select the
Switchover on Ethernet
LC Link Down check
box.
user with
Advanced
User
permissions
SO_ETH
Disabled
Disabled
Enabled
Disabled: switchover does
not occur when the
Ethernet LC link is down.
Enabled: to enable the
Reader to switchover
from the primary side to
the secondary side when
an Ethernet link to the LC
is down
N/A
