Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
USB Adapter IP or
Bluetooth IP
Address
From the General tab
on the Configuration
page:
Type an IP address in
the USB Adapter IP
Address field
user with
Advanced
User
permissions
USB_IP
192.168.2.50
N/A
sets the IP address for the
USB-to-Ethernet adapter
connected to one of the
CTM USB ports
only needed if a
USB to Ethernet
or Bluetooth
dongle is
anticipated to be
plugged in to
one of the USB
ports. Assign an
IPv4 address to
this interface.
Note: Please do
not use a USB-
to-Ethernet and
Bluetooth
dongle at the
same time
Default Gateway IP
From the General tab
on the Configuration
page:
Type an IP address in
the Default Gateway IP
Address field
Anyone
Note:
Initialize this
field to a IPv4
address if IP
traffic needs
to be routed
via a
gateway.
DFGWIP
0.0.0.0.0
N/A
tells the Reader the
default gateway IP
address of the gateway
device
Used to allow
the Reader on a
network to
connect to a
larger network
(such as the
Internet) via a
gateway device
(such as a
router)
