Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Ethernet 1 (LC
1Gbps) IP Address
From the General tab
on the Configuration
page:
Type an ETHERNET 1
port IP address in
Ethernet 1 (LC 1Gbps)
IP Address field..
anyone
LETHIF
192.168.1.50
N/A
Sets the IP address of the
Lane Controller ethernet
interface
Used to specify
an appropriate
ETHERNET 1 IP
address when
configuring an LC
network
Ethernet 1 (LC
1Gbps) Subnet
mask
From the General tab
on the Configuration
page:
Type the subnet mask
address in the Ethernet
1 (LC 1Gbps) Subnet
Mask field
anyone
LETHNM
255.255.255.0:0
N/A
Initializes this field to a
subnet mask for sites that
utilize subnet addressing.
Required by sites
that utilize
subnet
addressing.
Ethernet 2 (IRIF
100Mbps) IP
Address:
From the General tab
on the Configuration
page:
Type an ETHERNET 2
port IP address in the
Ethernet 2 (IRIF
100Mbps) IP Address
field..
anyone
PRIMIP
192.168.0.50
Primary
192.168.0.51
Secondary
N/A
Used to assign a unique
IPv4 address (e.g.
192.168.0.50) to the right
hand side (prime) side of
the reader.
Used to specify
an appropriate
ETHERNET 2 IP
address when
configuring an IR
network. Note:
This address
should be
provided by the
SI network
planner.
