Table 3-4: Miscellaneous information fields
Miscellaneous Information tab
Field
Status
Description
CTM Position
Primary
The CTM is installed on the primary side
Secondary
The CTM is installed on the secondary side
Active State
Active
CTM is active
Inactive
CTM is not active
CGC Health Status
Operational
CGC is operational
Failed
CGC Failure
Unknown
CGC Health status unknown
Board
Example: LB800, LB735
Provides information on the model of the single board
computer (SBC) board installed Type of Board installed
Other Side Config
Compare
Communication Down;
Same; Different
(BETA) Provides an indication as to configuration state of
peer CTM
Communication Down (peer CTM is not running so
configuration state is unknown)
Same (peer CTM configuration is identical to this CTM’s
configuration)
Different (peer CTM configuration is different that this
CTM’s configuration)
