Table 3-2: Power Supply Module fields
Power Supply Modules tab
Field
Status
Description
5V (primary)
On
DC input operational
Off
DC input failure
5V (secondary)
On
DC input operational
Off
DC input failure
15V (primary)
On
DC input operational
Off
DC input failure
15V (secondary)
On
DC input operational
Off
DC input failure
RF Modules
Table 3-3 lists and describes the fields in the RF Modules tab on the Status page.
