JANUS

Multi-Protocol Reader Ver. 2: Operating Instructions

Confidential UM 360450-210 Revision: C Page 53 of 288

These drawings and specifications contain confidential and proprietary information and are the property of Kapsch TrafficCom Canada Inc. and are issued in strict

confidence and will be kept confidential and used solely for the purpose intended and for no other purpose and shall not be transmitted, reproduced, copied, and/or

used as the basis for manufacture or sale of apparatus unless otherwise agreed to in writing by Kapsch TrafficCom Canada Inc.

FILE: UM 360450-210 REV C JANUS MPR2 OPERATOR-MAINTENANCE MANUAL.DOCX08/17/2015 11:42

Kapsch TrafficCom

Monitoring the Reader

You can monitor and gather information about the Reader from the CTM web interface using the Status

option in the left panel of the screen.

Note: For all of the following procedures, a laptop or desktop computer with a monitor needs to be

connected to the CTM Ethernet 1 port or USB port.

Reader status

The Status page in the CTM web interface displays the state of the communication links, the power

supply modules, and the CTM/CGC, and is useful for troubleshooting the Reader.
