The antenna sends and receives RF signals to and from the vehicle On Board Units (OBUs). The IAG
3 antenna is recommended for the MPR2 reader. See Antenna Specifications, page 264 for more
details. Figure 2-2 shows an illustration of the IAG 3 antenna, one of the recommended antennas for
the Multi-protocol Reader.
Figure 2-2: IAG 3 Antenna
IAG Antenna specifications
Table 2-1: IAG Antenna Specifications
P/N
Lane Kit #
Description
Width (in
inches)
Length (in
inches)
Depth (in
inches)
Weight
1
(in lbs)
Mounting
800260-015
802344-TAB
3x4 dipole
array
34.5
21.25
3.13
19
horizontal
800260-011
802344-TAB
3x3 Patch
34.5
31.75
2.3
28
horizontal
Note: Mounting information is provided as a guideline.
