Feature
JANUS
Badger
Notes
Load monitoring (CPU/Mem)
Y
Allows anomaly detection.
High Speed Margin Diagnostic
Y
Proof of concept for channels with
MRFM-S.
Trouble Log
Y
Separate trouble items from transaction
log
Transaction Log
Y
Temporary transaction log
Event log
Y
Y
JANUS: number of events limited only by
CF partition size. BGR & IAG: 10 events
Lane Controller serial interface check
Y
Via a loop-back adapter
Self-Test issued by Lane Controller
Y
LC commands a Reader to initiate/report
self-test.
Controller (CGC) serial number reported
Y
S/N of controller board is sent to Web IF
and log
Other
Network Time Protocol
Y
Allows NTP to sync date and time for all
Readers in a network
Feedback OBU activation Option 1
Y
Y
BGR205 firmware
Dual Reporting Mode (Redundancy
Reporting)
Y
Improved processing redundancy
handling (JANUS
®
Reader Phase 2).
HARDWARE
The JANUS® non-redundant Reader
uses the secondary side components.
The JANUS non-redundant MPR2
reader uses the primary side
components.
Y
The Badger non-redundant Reader uses
the primary side components
