Feature
JANUS
Badger
Notes
Feedback OBU support
Y
Beeper and LED on OBU supported
Maintenance Features
Web interface for local/remote Reader
HTTPS access and control
Y
Viewing/modify Reader configuration,
view status, download/run software,
manage OBU Status file
Real time reporting of transactions on
web interface
Y
Advanced / Simple parameter
presentation
Y
each web page has a functional group
Multiple users & permissions per user
Y
Zero re-configuration upon processor
module (CTM) replacement
Y
When a CTM is swapped, Reader
configuration parameters are retained in
the CFM (a non-volatile memory off board
from the CTM).
Save Reader Configuration File to laptop
(also IP addresses and permissions
passwords)
Y
Transition process is made easier. During
service process, reload the original
instead of manual setting many
parameters.
Remote reset (reboot)
Y
reset via a lane controller or the web
interface
Firmware download
Y
Maintain multiple firmware images
Y
At least 6 versions, including factory
image.
Automatic switchover recovery
Y
Reader will return control to Primary
without operator intervention.
USB stick transaction logging
Y
Diagnostics
Diagnostic Port
Y
Y
Test Tag Support
Y
Y
