Kapsch TrafficCom
Feature
JANUS
Badger
Notes
Lane Controller & Reporting Features
Filter out Non-IAG tags
Y
Non-IAG tags are not reported
configurable feature
Lane Assignment
Y
Y
Compatible performance (capture rate,
read/write operation)
Support 8 LC Serial ports
Y
Y
Max Serial port speed (kbps)
115.2
57.6
BGR max is on 5 ports
Support LC Ethernet interface
Y
Configurable 10/100/1000 Mbps
Support Inter-Reader Ethernet interface
Y
Configurable 10/100 Mbps for ORT use
Handshaking with Adjacent Readers
Y
Adjacent Readers are included in voting.
Also, conflicts in configurations of
adjacent Readers are identified.
Host Port support
Y
Multiplex transactions to single COM
Y
Y
Compatible transaction report and format
Re-Report
Y
re-report a tag in zone
Initial Read Report
Y
Post capture zone report
Y
Transaction buffering
Y
Y
JANUS: 400K non-volatile BGR: 80K
IAG: 1K
Reset transaction number
Y
Accept a Lane Controller command to
reset OBU transaction number to zero
Latency measurement & reporting
Y
Write protect transponder scratchpad
fields
Y
Status File Download for Feedback
OBUs
Y
up to 40 million OBUs in the file
