Term
Meaning
Reference or example
LPT
License Plate Transponder
An exterior tag in a weatherproof package mounted
using the front license plate mounting holes (a legacy
product now replaced by the FME)
MC
Main Controller
Intel-x86 based single-board computer that runs the
Reader software
MRFM-S
Smart RF Module
The analog portion of the Reader and the termination
point for coaxial cables from the antennas with
command driven Tx and Rx attenuation.
N/A
not available
NEC
National Electric Code
NEMA
National Electrical
Manufacturers Association
Sets standards for electrical components. Equipment
enclosures with a NEMA rating meet a certain
standard. NEMA-4 is generally considered watertight.
NTP
Network Time Protocol
OBU
On Board Unit
Transponder or tag
ORT
Open Road Tolling
ETC from high speed vehicles that do not slow down
and may straddle lanes
PC
Personal computer
PF
Programming failure
transponder programming by the Reader
Pgm
Program or programmed or
programming
context related usage
PID
Plaza ID
a configurable Reader parameter
PS
Power supply
PSM
Power Supply Module
PWA board to provide AC/DC power to the Reader
PTO
Programming timeout
PU
Programming unverified
transponder programming by the Reader
PWA
printed wiring assembly
All of the digital rack plug-in boards have PWAs
