Antenna Specifications
Antenna
IAG-1
IAG-3
P/N
800260-011
800260-015
Lane Kit #
802344-TAB
802344-TAB
Description
3x3 patch
3x4 dipole array
Width
(inches)
34.75
34.5
Length
(inches)
31.75
21.25
Thickness
(inches)
2.3
3.13
Weight
1
(lbs)
33
19
Mounting
horizontal
horizontal
Application
standard width
or ORT lane
Standard Width or
ORT lane
Straddle
(feet)
(min/max c
to c
5.5/6.5
5.5/6.5
Note: Mounting information is provided as a guideline.
Weight specified is applicable to the antenna structure only i.e. it does not include mounting hardware.
