JANUS

Multi-Protocol Reader Ver. 2: Appendix

Confidential UM 360450-210 Revision C Page 235 of 288

These drawings and specifications contain confidential and proprietary information and are the property of Kapsch TrafficCom Canada Inc. and are issued in strict

confidence and will be kept confidential and used solely for the purpose intended and for no other purpose and shall not be transmitted, reproduced, copied, and/or

used as the basis for manufacture or sale of apparatus unless otherwise agreed to in writing by Kapsch TrafficCom Canada Inc.

FILE: UM 360450-210 REV C JANUS MPR2 OPERATOR-MAINTENANCE MANUAL.DOCX 08/17/2015 11:42

Kapsch TrafficCom

Rebooting the CTM

This procedure outlines two ways of rebooting the CTM; using the ON/OFF switch on the CTM, and

using the Reboot button from the CTM web interface.

Prerequisites: To reboot from the browser interface, you must have Software Management

permissions.

Rebooting using CTM ON/OFF switch

1. Set the CTM ON/OFF switch to OFF.

2. After five seconds, set the CTM ON/OFF switch back to ON. The CTM POWER LEDs immediately

illuminate solid green. After 90 – 120 sec., the CTM STATUS LEDs illuminate their normal state (see LED

Status, page 201).

Rebooting from the browser interface

1. Login to the CTM web Interface.

Result: The following Home page appears.
