Constant busy state on sync bus
A Reader that erroneously holds the sync bus in a BUSY state causes all other Readers connected to
the bus to time-out while waiting for the READY state. As a result, all of their CTM SYNC LEDs will be
flashing red. Disconnect each Reader one at a time from the sync hub until the fault clears then
reconnect each Reader in the order of removal until the fault reappears. Service each faulty Reader.
Sync board Failure Indicator for incomplete cable connections
The CTM SYNC LED will flash steadily red if there is no activity on the Rx port on the terminal block of
the SPM (R+ and R- on the connector). If both transmit and receive connections are cut off from the
sync hub the indicator will flash red. If only the transmit connection is disconnected and there are other
Readers in the synchronization network, the CTM SYNC LED stays green.
