3. If the configuration is not already set, then set Superframe Sync Skip to Select Sync to Every
Superframe, set Add 2 Dummy Frames to No, set Type of Reader Syncing to to JANUS or BADGER,
as applicable.
4. If the superframes for all Readers will be equal (4, 5, 8 or 10 frames) go to Synchronization between
MPR2 Readers and perform step 1.
5. If the superframes will be configured as shown in Table 5-3, configure the Superframe Sync Skip and
Add 2 Dummy Frames parameters in the General tab on the Configuration page as outlined in Table
5-3 on page 183.
