The TX attenuation should be adjusted to obtain capture zones nominally 8-12 ft along direction
of vehicle traffic.
Attention: When installing or replacing a MRFM-S, RF cables, circulator, or antenna,
the lane must be re-tuned.
The Synchronization circuit
Reader synchronization ensures antennas from different Readers do not attempt to communicate
simultaneously with the same on-board unit (OBU). The synchronization circuit connects SPMs
together in a star network. The CTM does the synchronization of the RF module interrogation.
Prerequisites: Sync hub terminal block mounted in a location central to the Readers. The exact
location of this terminal block should be marked on a site map to aid system maintenance.
Readers arranged so that no Reader is farther than 1500 feet from the sync hub terminal block
Readers arranged so that the total synchronization network cable length is no greater than 2000
feet
No more than six (6) Readers in the synchronization circuit
Note: It is recommended that each synchronization cable have two or more spare conductors to
support future service repair calls.
Installing a synchronization circuit
1. Connect the Readers to the Sync hub terminal block as in Figure 5-9 on page 179.
Attention: Ensure that cables do not connect from the GND terminal on the SPM to the
Sync hub terminal block, as this can create a ground loop and affect synchronization
performance.
Note: Before you continue, you will need to gain access to the CTM web Interface through a computer or
service laptop connected to the Ethernet 1 port or the USB port of the Reader. See the following
procedures for more information.
Connecting a service laptop to the Reader on page 47
Changing the service laptop IP address on page 47
Testing the connection to the reader on page 47
Accessing the CTM web interface on page 47
2. Select the Configuration link on the left side panel.
Result: The following screen appears.
