Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Select Logs
From the Ethernet
Logging tab on the Log
Files page:
Select the check boxes
of the log files to be
sent, then, click the
Update Ethernet
Logging Configuration
button.
user with
View Log
Files and
Manage Log
Files
permissions
ELLOGS
trouble
trouble
tag
event
developer
debug
fifo
sets which log files are
sent via Ethernet
to select only the
log files you
want to receive
Perform Tests
(serial comms)
From the Diagnostics
Page:
Select the LPM COM
port to be tested from
the Test Enable/Disable
drop-down box, then,
click the Perform
Test(s) button.
user with
Advanced
User
permissions
N/A
N/A
N/A
tests the specified LPM
serial port
to ensure that a
specified LPM
port is
functioning
properly when
troubleshooting
communication
problems with
the LC
Custom sync timing
N/A
N/A
CHCSTE
0
min: 0
max: 1
Enables/disables custom
sync timing
N/A
Sync Frame Timeout
[us]
N/A
N/A
CHSFTO
338
min: 0
max: 65535
Specifies how long the
Reader waits for the sync
pulse during the normal
sync process.
N/A
