Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Tertiary Ethernet
Destination IP
Address (IREADs
only)
From the LC tab on the
Configuration page:
anyone
LC3IPP
N/A
N/A
this specifies the Tertiary
Destination IP address and
port.
Note: Only IREADs are
sent over this link
N/A
Status Reports
From the LC-extended
tab on the
Configuration page:
anyone
EIR_SR
Disabled
Disabled
Enabled
Specifies which Extended
Information values are to
be included in Status
Reports sent to the Lane
Controller.
N/A
Transaction Reports
(Initial-Read,
Voting, Post-
Capture,
Est.Veh.Speed)
From the LC-extended
tab on the
Configuration page:
anyone
EIR_TN
Disabled
Disabled
Enabled
Specifies which Extended
Information values are to
be included in Transaction
Reports (Initial Read,
Voting, Post-Capture,
and/or Estimate Vehicle
Speed) reports sent to the
Lane Controller.
N/A
Raw Handshake
Reports
From the LC-extended
tab on the
Configuration page
anyone
EIR_RH
0
min: 0
max: 31
Specifies which Extended
Information values are to
be included in Raw
Handshake reports sent to
the Lane Controller.
N/A
