Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Serial Port
From the LC tab on the
Configuration page:
With serial
communications
enabled, select the
appropriate LPM COM
Port from the Serial
Port drop-down
anyone
LCSERL
per-instance
defaults:
instance:0
value:0
instance:1
value:1
instance:2
value:2
instance:3
value:3
instance:4
value:4
instance:5
value:5
instance:6
value:6
min: 0
max: 7
Specify the physical serial
port on which to send
transaction reports.
Note: Channels can report
on separate serial ports,
or can be multiplexed
onto a single serial port.
to configure
which LPM COM
Port sends data
for a specific
MRFM-S channel
Destination IP
Address
From the LC tab on the
Configuration page:
anyone
LCIPPT
N/A
N/A
this specifies the
destination IP address and
port.
N/A
Dual Destination IP
Address
From the LC tab on the
Configuration page:
anyone
LC2IPP
N/A
N/A
this specifies the Dual
Destination IP address and
port.
N/A
