Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Status message
buffering
From the LC tab on the
Configuration page:
Enable or disable the
Status message
buffering checkbox.
user with
Advanced
User
permissions
LcStBf
Disable
Disable
Enable
If enabled, instructs the
Reader to buffer status
messages in the event of a
communications link loss
with the Lane Controller.
N/A
LC Ethernet TCP-
Socket Local Port
From the LC tab on the
Configuration page
user with
Advanced
User
permissions
LcEtPn
default: 6666
min: 1024
max: 65535
Use to select the local TCP
Protocol Port Number
that the Reader will listen
on to accept incoming TCP
connections from theLane
Controller.
LC Ethernet TCP-
Socket Timeout
From the LC tab on the
Configuration page:
With at least one RF
Channel configured to
send data to the LC via
Ethernet, type a time, in
milliseconds, in the LC
Ethernet TCP-Socket
Timeout check box.
user with
Advanced
User
permissions
LcEtTo
500
100-5000
sets the timeout for a
response from the LC via
the LC Ethernet network
to determine if
there is an
Ethernet
communication
problem
between the
Reader and the
LC
