Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
FDM Enable
From the Channel tab
on the Configuration
page:
Select the FDM Enable
checkbox.
anyone
FDMEBL
Disabled)
Disabled)
1 (Enabled)
Disabled: FDM selections
not available to configure.
Enabled: FDM selections
available for
configuration.
Used for ATA,
6B, 6C, Sego
protocols
FDM RF State
From the Channel tab
on the Configuration
page:
Select one of the
choices offered from
the drop down menu
for every appropriate
channel.
anyone
RFFSTS
0 (Offline)
0 (Offline)
1 Active
2 Guard
Offline means the frame
timing for this channel is
preserved, but the MRFM-
S module is off.
Active means the MRFM-S
module is on and reports
transactions on this
channel.
Guard means the MRFM-S
module is on, but
transactions assigned to
this channel are not
reported.
Used for ATA,
6B, 6C, Sego
protocols
