Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Toll Rate Table
Select
From the Toll
Rate/Balance tab on
the Configuration page:
with BAT 1 enabled,
select one of four toll
rates from the Toll Rate
Table Select drop-down
box for each RF channel
click the Update TRBA
Configuration button
anyone
TRBATS
Table 1)
Table 1)
(Table 2)
(Table 3)
3 (Table 4)
sets the toll rate for each
RF Channel based on the
table selected
to allow a
Reader to charge
different rates,
depending on
which lane a
vehicle is in
Entry/Exit Reader
From the Toll
Rate/Balance tab on
the Configuration page:
with BAT 2 enabled,
select Entry Reader or
Exit Reader
click the Update TRBA
Configuration button
anyone
TRBAER
Entry Reader)
Entry Reader)
1 (Exit Reader)
Entry Reader: This Reader
location is used as the
highway entry point when
calculating the toll
Exit Reader: This Reader
location is used as the
highway exit point when
calculating the toll
to allow a
Reader to charge
a different rate
on entry and exit
