Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Toll Rate / Balance adjustment tab
Toll Rate/Balance
adjustment
From the Tag
Programming tab on
the Configuration page:
with OBU Feedback
disabled, select the Toll
Rate/Balance
adjustment check box.
anyone
rw_TRB
Disabled)
Disabled)
1 (Enabled)
Disabled: Reader does not
adjust Toll Rate or Balance
Enabled: Reader is
responsible for adjusting
Toll Rate and Balance in
OBU.
to allow the
Toll/Rate
Balance
adjustment to be
made by the
Reader and
access
configuration
settings
TRBA BAT
Processing Type
From the Toll
Rate/Balance tab on
the Configuration page:
with Toll Rate/Balance
adjustment enabled,
select BAT 1-Fixed Toll
or BAT 2-Variable Toll,
then,
click the Update TRBA
Configuration button
anyone
TRBTYP
BAT 1-Fixed
Toll)
0 (BAT 1-Fixed
Toll)
1 (BAT 2-
Variable Toll)
BAT 1-Fixed Toll: the
Reader charges a toll
based on the RF
Channel(i.e. lane) and
type of vehicle
BAT 2 –Variablt Toll: the
Reader charges a toll
based on whether the
Reader is at an entry or
exit
to enable either
fixed toll or
variable toll
charges and
provide access to
related toll
options
