Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
OBU Visual
Feedback
From the OBU
Feedback tab on the
Configuration page:
With OBU feedback
enabled and Type 1
selected, select a
feedback option from
the OBU Visual
Feedback drop-down
box.
anyone
OBUVIS
Off
Off
Green: 2s
Red: 2s
Yellow: 2s
turns on and specifies the
type of visual feedback an
OBU provides
to configure how
long and what
color an OBU LED
flashes to
indicate a
successful
transaction
OBU Feedback Type 2
Valid Tag: Audible
From the OBU
Feedback tab on the
Configuration page:
With OBU feedback
enabled, and Type 2
selected, select a
feedback option from
the OBU Audible
Feedback drop-down
box.
anyone
O2VLDA
Off
Off
4 cycles: 0.25s
ON, 0.25s OFF
1 cycle: 1.5s ON
3 cycles: 0.5s
ON, 0.2s OFF
Specifies the audible
feedback to provide for
a valid tag
to configure how
long and how
many times an
OBU beeps to
indicate a
successful
transaction
