Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
TC Date/Time
From the Tag
Programming tab on
the Configuration page:
With TCP enabled,
select TC Date/Time.
anyone
TCDTTM
Disabled
Disabled
Enabled
Disabled: Reader
Date/Time not written to
OBU TC data fields.
Enabled: Reader
Date/Time written to OBU
TC data fields.
to keep a record
in OBUs of the
TC transaction
time
RW Format
From the Tag
Programming tab on
the Configuration page:
With TCP enabled,
select the RW Format
check box.
anyone
rw__RW
Disabled
Disabled
Enabled
Disabled: RW Format not
affected
Enabled: Reader controls
how OBU scratchpad
memory is encoded
determines how
the data stored
in OBU
scratchpad
memory is
encoded
Lane Number
(enable)
From the Tag
Programming tab on
the Configuration page:
With TCP enabled,
select the Lane Number
R/W check box, then,
press Enter or select a
different tab.
anyone
rwLANE
Enabled
Disabled
Enabled
enables lane number
programming
to enable ability
to set a specific
lane number for
each RF channel
