Kapsch TrafficCom
Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
OBU Feedback
From the Tag
Programming tab on
the Configuration page:
Select the OBU
feedback check box.
Note: If the checkbox is
grayed out, it is because
the Toll Rate/Balance
Adjustment checkbox is
checked. Uncheck to
activate the OBU
feedback checkbox
anyone
rw_OBU
Disabled
Disabled
Enabled
Disabled: programs
feedback-type OBUs to
not provide feedback
Enabled: programs
feedback-type OBUs to
provide feedback
to configure
feedback-type
OBUs to notify
when an ETC
transaction has
occurred.
Toll Rate / Balance
Adjustment
From the Tag
Programming tab on
the Configuration page:
Select the Toll Rate /
Balance Adjustment
check box.
Note: If the checkbox is
grayedout, it is because
the OBU feedback
checkbox is checked.
Uncheck to activate the
Toll Rate/Balance
Adjustment checkbox.
anyone
rw_TRB
Disabled
Disabled
Enabled
Disabled: blanks out the
Toll Rate / Balance
Adjustment tab.
Enabled: Reader is
responsible for adjusting
Toll Rate and Balance in
OBU.
to allow the
Toll/Rate
Balance
adjustment to be
made by the
Reader and
access
configuration
settings.
