Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Transaction number
programming
From the Tag
Programming tab on
the Configuration page:
With Transaction
number programming
enabled, select the
appropriate calculation
type from the
Transaction number
programming drop-
down box.
anyone
TFRM__
Reprogram with
16 bit
sequential
transaction
number
Don’t
reprogram
transaction
field
Reprogram with
16 bit random
number
Reprogram with
16 bit
sequential
transaction
number
Reprogram with
8 bit random
number and 8
bit sequential
number
sets the way the Reader
creates an OBU
transaction number
to choose how
the Reader
determines OBU
transaction
numbers
