Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
R/W Enable Plaza ID
From the Tag
Programming tab on
the Configuration page:
With TCP enabled,
select the Plaza ID
check box.
anyone
rw_PZID
N/A
N/A
enables Plaza ID to be
written to OBUs
to write Plaza ID
to OBUs and
access the Plaza
ID field
Agency ID (enable)
From the Tag
Programming tab on
the Configuration page:
With TCP enabled,
select the Agency ID
check box.
anyone
rw_AID
Enabled
Enabled
Disabled
enables Agency ID to be
written to OBUs
to write the
agency ID to
OBUs and access
the Agency ID
field
Transaction number
programming
(enable)
From the Tag
Programming tab on
the Configuration page:
With TCP enabled,
select the Transaction
number programming
check box.
anyone
rw_TXN
Enabled
Enabled
Disabled
enables a transaction
number to be written to
the OBU
to write a
transaction
number to OBUs
and to access the
transaction
number
programming
options
