Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Test Tag State
From the Test Tags tab
on the Configuration
page:
Enter a time, in
seconds, in the Test Tag
Period field, then.
user with
Advanced
User
permissions
RFTTST
Disable
Disable
Enable
Enable means start
checking for test tags and
switch-over if the Multiple
Fault Threshold has been
reached.
N/A
Lane Assignment tab
IAG
6B
6C
Allegro
ATA
SeGo
From the Lane
Assignment tab on the
Configuration page:
Select First to
Read/Program,
Majority , or
Interpolated from the
Lane Assignment
Algorithm box.
user with
Advanced
User
permissions
VTALGO
VTAG6B
VTAG6C
VTAGAG
VTAGAA
VTAGSG
Majority
First to read
program
Majority
2-Interpolated
runs the selected tag
assignment algorithm
to set which
algorithm is used
for determining
OBU lane
assignment
between
multiple Readers
