Command
How is this command
executed?
Who can
execute this
command?
Parameter
Name
Default
Parameter
Value
Parameter
Range/Options
What does this
command do?
What is the
purpose of this
command?
Test Tags tab
Test Tag Single Fault
Threshold
From the Test Tags tab
on the Configuration
page:
Enter a number in the
Test Tag Single Fault
Threshold field.
user with
Advanced
User
permissions
SFT___
6
1-99
sets the number of
consecutive test tag faults
before a channel is
considered bad
to continuously
monitor channel
quality and set a
failure threshold
Test Tag Multiple
Fault Threshold
From the Test Tags tab
on the Configuration
page:
Enter a number in the
Test Tag Multiple Fault
Threshold field, then,
press Enter or select a
different tab.
user with
Advanced
User
permissions
MFT___
8
1-8
sets the number of bad
channels that trigger a
switchover
to continuously
monitor channel
quality and set a
failure threshold
for triggering a
switchover
Test Tag Period
From the Test Tags tab
on the Configuration
page:
Enter a time, in
seconds, in the Test Tag
Period field, then.
user with
Advanced
User
permissions
TTP___
30
10-99
sets the test tag period
to set the
frequency of test
tag checks
