Installation Instructions

Instructions
K&H CleanFlow
Small filtering water bowl
with auto fill reservoir tank
Patent Pending
Thank you for purchasing a K&H Clean Flow filtering water bowl. With proper care and
cleaning, your Clean Flow should offer years of hassle free water filtering service for your pets.
Operating instructions.
1. Remove the lid from the pump/filter compartment.
2. Remove filter from compartment and thoroughly rinse the filter with cool water. This will remove
loose charcoal from the filter media.
3. Thoroughly rinse the entire bowl and pump compartment.
4. Remove the cap from the water reservoir tank and thoroughly rinse the tank.
5. Fill the bowl with cool water to about 50% full while lifting the front of the bowl slightly to
release air from inside the pump tube.
6. Fill the bowl the rest of the way.
7. Slide the filter into it’s location in the filter/pump compartment, rounded edges toward bottom.
8. Place the bowl in the desired location.
9. Plug the bowl into an electrical outlet.
10. Fill the reservoir tank with water.
11. Plug the cap hole with the attached no-spill plug. Now screw the plugged cap onto your reservoir
tank.
12. Gently place the filled reservoir tank into the lid of the rear bowl compartment.
13. The spike will release the auto-fill non spill cap. Your tank will now automatically fill your pet’s
bowl for you!
Note: if water flow does not start immediately, lift the front edge of the bowl slightly to help release air
from pump tube. This will help the pump “grab” water.
Cleaning instructions.
1. Unplug the unit from the electrical outlet.
2. Carefully carry your Clean Flow to sink.
3. Remove pump/filter compartment cover.
4. Remove filter and rinse thoroughly. Set aside.
5. Remove pump from compartment.
6. Remove tube from pump.
7. Clean water tube using the supplied small cleaning brush.
8. Hand wash entire bowl with hot soapy water or place into
dishwasher.
9. Rinse the bowl thoroughly and re-assemble.
10. Follow operating instructions #4 through #8.
11. Note: HAND WASH the reservoir tank using the supplied
cleaning brush.
12. The reservoir tank IS NOT dishwasher safe.
Periodic pump cleaning.
Every month or so, your pump should be quick cleaned.
1. Using a flathead screwdriver or other dull prying instrument,
pry the main cover off the pump. See figure 1.
2. Remove the oblong impeller cover. See figure 2.
3. Remove impeller. See figure 3.
4. Rinse impeller and pump assembly well.
5. Use a cotton swab to clean impeller receptacle in pump body.
6. After rinsing all parts well, place impeller back into pump body.
7. Place oblong impeller cover over the inserted impeller.
8. Replace main cover onto pump.
Proper periodic cleaning will greatly extend the life of your pump.
