User's Manual

Appendices
E1 Spread Spectrum Radios
10-13
2 TX+ （OUTPUT）transmit data+
3 RX+ (INPUT) receive data+
4
5
6
7 GND
8
9 RC- (OUTPUT) receive clock-
10
11
12 TC- (OUTPUT) transmit clock-
13
14 TX- (OUTPUT) transmit data-
15 TC+ (OUTPUT) transmit clock
16 RX- (INPUT) receive data-
17 RC+ (OUTPUT) receive clock+
18
19
20
21
22
23
24
25
Table 10-19 Balanced E1 Interface(RJ-48)
RJ-48 Description Direction
1 RX TIP Input
2 RX Ring Input
3 RX Shield
4 TX TIP Output
5 TX Ring Output
6 TX Shield
7
8
