User's Manual

Appendices
E1 Spread Spectrum Radios
10-8
8 Link Peer IP:
Display peer Link port IP
address
Set the configuration via textmenu, and
manifest when PPP connection are
established
1
LAN-Port:
Dis/1E1/2E1/3E1/4E1
Activate E1 interface number
which should be used for
Ethernet transmission.
Set the configuration via LCD, textmenu,
and SNMP software
2 Actual: None/n E1
Display actual E1 interface
number which has been
transferred to Ethernet
transmission.
Set the configuration via LCD, textmenu,
and SNMP software
3 Auto-Nego: None/Dis/En
Activate/close Ethernet
auto-negotiation function.
Set the configuration via LCD, textmenu,
and SNMP software
4 Duplex: None/Full/Half
The configuration of Ethernet
interface duplex.
Set the configuration via LCD, textmenu,
and SNMP software
5 Speed: None/10M/100M
The configuration of Ethernet
interface speed.
Set the configuration via LCD, textmenu,
and SNMP software
LAN Info
6
Buffer:
None/Small/Large
The configuration of Ethernet
interface buffer.
Set the configuration via LCD, textmenu,
and SNMP software
1 S-Test: Start/Testing
Activate Self Test function/Self
Test status display
2 S-Test Result Self Test result displays
Self Test
Info
3 Close-Test Close Self Test function
1 Link ID:n Display and set the link ID
Set the configuration via LCD, textmenu,
and SNMP software Link
Info
2 MODEM: On/Off
Display remote dialup modem
status
Display if any remote dialup modem is
connected or not
