User's Manual

Appendices
E1 Spread Spectrum Radios
10-7
7 IF-Loop: En/Dis Set IF Loopback
Perform loopback test from IF interface for
the convenience of testing the IDU’s
stability
8 RF-Loop: En/Dis Set RF Loopback
Perform loopback test from RF interface for
the convenience of testing the IDU’s
stability
9 Close-Test: Y/N Close all test Y: close N: cancel
1 Link ID: n Display the remote link ID
Display the link ID of the remote equipment;
n=1~255
2 Far-end OK/Loss
Display the connection status
of remote end
OK: in connection
Loss: remote monitor function lost
3
R-AUX1:
RS-232/RS-422
Display remote AUX1 status Display remote AUX1 status
Remote
Info
4
R-AUX2:
ASY-CH/SYN-CH
Display remote AUX2 status Display remote AUX2 status
1 ETH IP: Display ETH port IP address Set the configuration via textmenu
2 ETH Mask: Display ETH port subnet mask Set the configuration via textmenu
3 NMS1 IP: Display NMS1 port IP address
Set the configuration via textmenu, and
manifest when PPP connection are
established
4 NMS1 Peer IP:
Display peer NMS1 port IP
address when more than two
equipments are connected in
the local station
Set the configuration via textmenu, and
manifest when PPP connection are
established
5 NMS2 IP: Display NMS2 IP address
Set the configuration via textmenu, and
manifest when PPP connection are
established
6 NMS2 Peer IP:
Display peer NMS2 port IP
address when more than two
equipments are connected in
the local station
Set the configuration via textmenu, and
manifest when PPP connection are
established
IP Info
7 Link IP:
Display Link port IP address.
Link means RF connection
between two stations
Set the configuration via textmenu, and
manifest when PPP connection are
established
