User's Manual

Appendices
E1 Spread Spectrum Radios
10-3
Stability ±50ppm
Power -4dBm±2dBm
Return Loss
VSWR≦1.3
Frequency 11.0592MHz
Stability ±50ppm
Power 150~180mVpp
Monitoring Signal
Return Loss
VSWR ≦ 1.3
Table 10-7 Power
DC Input -48VDC (-36~ -72V)
Power Consumption < 45 watts
AC Input (optional) 100-240VAC 50-60Hz
Connector Barrier strip, plug-in type
Table 10-8 Service Channel
Frequency 300-3400Hz
Impedance 600 ohm balance
Telephone
Interface RJ-11
Bit Rate
≦9600 baud
Protocol RS-232
Monitoring Data
(NMS1)
Interface DB-9(Female)
Bit Rate
≦9600 baud
Protocol RS-232
Monitoring Data
(NMS2)
Interface DB-9(Male)
Bit Rate
≦9600 baud
Protocol RS-232
Computer Data
(AUX1)
Interface DB-9(Female)
Bit Rate
≦9600 baud
Protocol RS-232
Computer Data
(AUX2)
Interface DB-25(Female)
Type Photo-coupled (TTL)
Interface DB-26(Female)
Number 8
Isolation 3000 VAC(rms)
User Input
LED Power Dissipation 90 mW
