Management Application Structure
E1 Spread Spectrum Radios
9-4
Figure 9-3 Remote Management via External Modem
Please refer to example 1 for configuration of Point-to-Point. This example focuses on configuration of external
modem.
Table 9-3 Example for managerial application(3)
Item Modem 1 Note
ETH(10BaseT) IP
192.168.168.1 Refer to section 8.1.5
ETH(10BaseT) Mask
255.255.255.0 Refer to section 8.1.5
NMS2 Data Rate
115200 Refer to section 8.1.2
NMS2 Usage
External Wired Modem Refer to section 8.1.2
NMS2 Local IP
N/A Refer to section 8.1.2
NMS2 Peer IP
N/A Refer to section 8.1.2
NMS2 Interface
Activation
Enable Refer to section 8.1.2
Model Mode
Dial Out at Once Refer to section 8.1.3
Telephone Number for
Outgoing Call
PSTN Telephone Number Refer to section 8.1.3
Username
N/A Refer to section 8.1.3
Modem Authentication
Protocol
N/A Refer to section 8.1.3
PAP Password
N/A Refer to section 8.1.3
CHAP Password
N/A Refer to section 8.1.3
