TM-H1950CG [TM-H1950CG/E/TM-H1950CG/U] OPERATING INSTRUCTIONS COLOR VIDEO MONITOR FRANÇAIS INSTRUCTIONS DEUTSCH TM-H1950CG TM-H1750CG ENGLISH BEDIENUNGSANLEITUNG : FARB-VIDEO-MONITOR MANUEL D’INSTRUCTIONS : MONITEUR VIDÉO COULEUR MANUALE DI ISTRUZIONI : MONITOR VIDEO A COLORI INSTRUCCIONES : MONITOR DE VIDEO A COLOR !"#$%&'(&) ITALIANO For Customer Use: Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.
TM-H1950CG 1-2 No.
SAFETY PRECAUTIONS WARNINGS To prevent fire or shock hazard, do not expose this monitor to rain or moisture. Dangerous high voltages are present inside the unit. Do not remove the back cover of the cabinet. When servicing the monitor, consult qualified service personnel. Never try to service it yourself. WARNING : THIS APPARATUS MUST BE EARTHED. Machine Noise Information Ordinance 3.
TM-H1950CG CONTROLS AND FEATURES FRONT VIEW 1 CHROMA CONTRAST VOLUME/SELECT MENU UNDER SCAN COLOR OFF BLUE CHECK ASPECT A C SLOT D B POWER 15 CHROMA CONTRAST TM-H1950CG PHASE VOLUME/SELECT MENU UNDER SCAN COLOR OFF BLUE CHECK ASPECT BRIGHT A B C SLOT D PHASE BRIGHT 2 3 POWER INPUT SELECT 4 5 6 7 8 9 10 11 12 13 14 INPUT SELECT (Front view of TM-H1950CG shown) 1 Tally lamp Lights when the tally control signal is ON.
TM-H1950CG REAR VIEW VIDEO A IN OUT 16 SLOT 18 REMOTE 17 VIDEO B 19 IN OUT VIDEO A IN OUT VIDEO B IN IN 20 IN Y/C OUT Y/C OUT AUDIO A IN OUT AUDIO B IN OUT OUT AUDIO A (Rear view of TM-H1950CG shown) 21 OUT AUDIO B 22 IN 20 Video B (Y/C) terminals [VIDEO B Y/C IN/OUT] OUT 16 Input card slot (SLOT) Optional input cards can be installed in this slot. Input cards are not provided when you purchase this monitor.
(cont’d) TM-H1950CG 1-6 CONTROLS AND FEATURES CONTROLS AND FEATURES (INPUT CARD: OPTIONAL) REAR VIEW COMPONENT/RGB INPUT CARD (OPTIONAL: IF-C01COMG) 1 Video input/output terminals Input (IN) and output (OUT) terminals for component (color deference) or RGB signals. The IN and OUT terminals are bridge-connected. (When no cable is connected to the OUT terminal, the input signal is automatically terminated.
PREPARATION INSTALLING THE INPUT CARD ATTACHING THE POWER CORD HOLDER 1. Turn off the Color Video Monitor’s main power and unplug the power cable from the AC outlet. 2. Unscrew the screws and remove the slot cover from the slot (on the rear side of the monitor) in which you are going to install the card. The provided Power Cord Holder prevents the AC power cord from being accidentally disconnected from the AC inlet. The Power Cord Holder consists of two parts; a case and cover. 1.
TM-H1950CG 1-8 HOW TO HANDLE BASIC OPERATIONS BASIC OPERATION VIDEO SIGNAL CONTROLS ON : Power turns ON. (Power indicator: lit) Green : The main power is ON, and the monitor’s power is ON (in the normal operation mode). OFF : Power turns OFF. (Power indicator: unlit) Orange : The main power is ON, but the monitor’s power is OFF (in the standby mode) Unlit : The main power is OFF.
HOW TO USE THE MENU FUNCTIONS DISPLAY AND SELECTION IN THE
Settings Image sub adjustment Selects CONTRAST/BRIGHT/CHROMA/PHASE. The selected setting screen is shown. Select the function display for adjustment. CONTRAST Adjusts contrast. –10 –9 • • –01 00 +01 • • +09 +10 BRIGHT Adjusts brightness. – 10 –9 • • – 01 00 +01 • • +09 +10 CHROMA Adjusts color density. *1 –10 –9 • • –01 00 +01 • • +09 +10 PHASE Adjusts hue.
BASIC CONNECTION EXAMPLE VIDEO B (Y/C) Connection Example (Select Input B (Y/C)) Notes: • Before connecting your system, make sure that all units are turned off. • The illustration below shows some examples of different connections. Terminal connections may differ depending on the component connected. Be sure to refer to the instructions provided with the unit(s) you are connecting. • Each pair of input (IN) and output (OUT) terminals are bridge-connected.
TM-H1950CG SPECIFICATIONS MODEL TM-H1950CG Type TM-H1750CG Color video monitor Color system PAL, NTSC (3.58) Picture tube 49 cm (19") measured diagonally, 90° deflection, in-line gun, trio-dot type (phosphor dot-trio pitch 0.27 mm) Effective screen size 44 cm (17") measured diagonally, 90° deflection, in-line gun, trio-dot type (phosphor dot-trio pitch 0.27 mm) Width 365.8 mm (14-5/8") Height 274.3 mm (10-7/8") Diagonal 457.2 mm (18") Width Height Diagonal 327.5 mm (12-7/8") 246.
TM-H1950CG Dimensions [TM-H1950CG] Unit : mm (inch) < Side View > < Front View > 496 (19-5/8") 485 (19-1/9") 440 (17-3/8") 1.5 (1/16") VOLUME/SELECT MENU UNDER SCAN COLOR OFF BLUE CHECK ASPECT A BRIGHT C B SLOT D POWER INPUT SELECT 380.4 (15") 95.7 (3-7/8") 336 (13-1/4") 5 (1/4") PHASE 5 (1/4") CHROMA CONTRAST TM-H1950CG 195.5 (7-3/4") 284.3 (11-1/4")* 375 (14-7/8") 375 (14-7/8")* ENGLISH ø 20 (7/8") * Asterisks (*) are used to indicate front panel dimensions.
TROUBLESHOOTING Solutions to common problems related to your monitor are described here. If none of the solutions presented here solves the problem, unplug the monitor and consult a JVC-authorized dealer or service center for assistance. Problems This monitor is provided with an external control terminal. MAKE (make contact) or TRIG. (trigger) system can be selected by the setting of REMOTE SYSTEM in the .
MEMO MEMO Y/C (Mini DIN 4 pin) terminal specification 2 4 1 3 OUT 2 4 1 3 Pin No. IN Y/C Signal 1 GND (Y) 2 GND (C) 3 Y 4 C No.51961 APPENDIX: CONNECTION EXAMPLES FOR THE SDI INPUT CARD ● To use the SWITCHED OUT terminal, the main power must be ON. (Unlike a bridged output, this connector outputs relocked digital signals.) ● Signal output from the SWITCHED OUT terminal can be changed by selecting INPUT C (SDI 1) or INPUT D (SDI 2).
