COMPACT COMPONENT SYSTEM SYSTEME DE COMPOSANTS COMPACT FS-P5 — Consists of CA-FSP5 and SP-UXP5. COMPACT DIGITAL AUDIO CD-R/RW PLAYBACK STANDBY/ON C O M P A C T C O M P O N E N T S Y S T E M F S · P 5 CLOCK STANDBY / ON AHB PRO CD / TAPE FM/AM MD/AUX STANDBY/ON DIRECT OPERATING DIMMER DISPLAY PROG SOUND MODE SLEEP RANDOM REPEAT SOUND FUNCTION VOLUME TIMER MD/AUX AUTO FM/AM PRESET FM MODE TAPE CD CD REV.
Warnings, Cautions and Others Mises en garde, précautions et indications diverses CAUTION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Instructions for safe use (Statement in accordance with the UL standards) 1) Read Instructions — Read carefully this instructions for your safe use before this appliance is installed, wireconnected, and operated. 2) Retain Instructions — For your future reference, retain this instruction. 3) Follow Instructions — Follow and obey all warnings, cautions and instructions marked on this appliance and this instruction.
Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference. About This Manual Power sources This manual is organized as follows: • When unplugging from the wall outlet, always pull the plug, not the AC power cord. • The manual mainly explains operations using the buttons on the remote control.
Contents Location of the Buttons and Controls ....................... 3 Playing Back CDs (CD/CD-R/CD-RW) .................. 12 Front Panel ................................................................. 3 Remote Control .......................................................... 5 Playing Back the Entire CD — Normal Play ........... 12 Basic CD Operations ................................................ 12 Programming the Playing Order of the Tracks — Program Play .......................................
Location of the Buttons and Controls Become familiar with the buttons and controls on your unit. Front Panel Front Panel 1 p q COMPACT DIGITAL AUDIO CD-R/RW PLAYBACK w e STANDBY / ON C O M P A C T C O M P O N E N T S Y S T E M F S - P 5 CLOCK r 2 STANDBY / ON 3 4 t AHB PRO 5 CD / TAPE FM/AM MD/AUX DIRECT OPERATING SOUND FUNCTION VOLUME TIMER 6 y 7 u i o REV.MODE ; a REC 8 REC PHONES s AUTO REVERSE 9 d –3– EN01-11.FS-P5[J] 3 01.4.
Continued Display Window 2 1 3 [DAILY REC SLEEP] REC CLOCK PRGM RANDOM 4 ALL BASS SOUND MONO ST 6 5 7 8 9 See pages in the parentheses for details. Front Panel Display Window 1 Remote sensor 2 (STANDBY/ON) button and STANDBY/ON lamp (9, 14, 19) 3 TAPE 2 3 button (9, 15, 16) Pressing this button also turns on the unit. 4 CD 3/8 (play/pause) button (9, 12, 17) Pressing this button also turns on the unit.
Remote Control Remote Control t 1 2 3 4 5 6 7 8 y 9 STANDBY/ON 1 2 3 4 5 6 7 8 9 r DIMMER DISPLAY PROG SLEEP MD/AUX RANDOM REPEAT SOUND MODE AUTO FM/AM PRESET FM MODE u TAPE CD i o ; CD p q w p q w e r t y a CANCEL MULTI KEY SET u s i AHB PRO VOLUME d e o ; a s d REPEAT button (14) DIMMER button (10) DISPLAY button (9) PROG (program) button (13) RANDOM button (14) SOUND MODE button (10) AUTO PRESET button (11) CD 0 (disc tray open/close) button (12) Pressing this button also t
Getting Started Continued Supplied Accessories Connecting Antennas Make sure that you have all the following items. The number in the parentheses indicates the quantity of the pieces supplied. FM antenna A ENN • • • • ANT AM loop antenna (1) FM antenna (1) Remote control (1) Batteries (2) EXT P AM M LOO A FM antenna (supplied) 75 FM XIAL A CO If anything is missing, consult your dealer immediately.
Connecting Speakers AM antenna ] ] ANTENNA 2 1 3 Vinyl-covered wire (not supplied) Red 1 AM EXT AM LOOP RIGHT LEFT MAIN SPEAKERS FM 75 COAXIAL SPEAKER IMPEDANCE MIN 6 Black Speaker cords 2 AM loop antenna (supplied) Right speaker 1 Connect the AM loop antenna to the AM LOOP terminals as illustrated. Left speaker 1 Press and hold the clamp of the speaker • If the AM loop antenna wire is covered with vinyl, remove the vinyl by twisting it as shown in the diagram.
To remove the speaker grilles The speaker grilles are removed as the illustrations below. Holes Projections To connect audio equipment with an optical digital input terminal You can record CD sound onto the connected digital equipment. Protective plug OPTICAL DIGITAL OUT Speaker grille Before connecting the other equipment, remove the protective plug from the terminal. To remove the speaker grille, inserting your fingers at the top of the speaker grille, pull towards you.
Common Operations Turning On the Power 2 Press ¢ or 4 to adjust the hour, then press CLOCK. When you press the play button — CD 3/8, TAPE 2 3, or the source selecting button — FM/AM, and MD/AUX, the unit automatically turns on and starts playback if the source is ready. The minute digits start flashing on the display. CLOCK To turn on the unit, press (STANDBY/ON). The STANDBY/ON lamp on the unit lights green. STANDBY/ON CLOCK STANDBY/ON 3 Press ¢ or 4 to adjust the minute, then press CLOCK.
Adjusting the Volume Reinforcing the Bass Sound You can adjust the volume level only while the unit is turned on. The volume level can be adjusted between “VOLUME 0” and “VOLUME40.” You can reinforce the bass sound to maintain rich (“AHB 1” and “AHB 2”), full bass at low volume. This function only affects the playback sound, but does not affect your recording. When using the remote control, press VOLUME + to increase the volume or press VOLUME – to decrease it.
Listening to FM and AM Broadcasts Tuning in a Station 3 Repeat steps 1 and 2 to store stations for the other band. 1 Press FM/AM. The unit automatically turns on and tunes in the previously tuned station (either FM or AM). • Each time you press the button, the band alternates between FM and AM. FM/AM When you cannot automatically store stations you want Stations with weak signals cannot be detected with this automatic presetting. To store such a station, use the manual presetting.
Playing Back CDs (CD/CD-R/CD-RW) This unit has been designed to playback the following CDs: • CD • CD-R • CD-RW Continued 3 Press CD 3/8. CD The disc tray automatically closes and the first track of the CD starts playing. Continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage the unit. Track number Elapsed playing time • The CD automatically stops when the last track of the CD has finished playing. General Notes To stop playing, press 7.
Programming the Playing Order of the Tracks — Program Play To check the program contents You can arrange the order in which tracks play before you start playing. You can program up to 20 tracks. You can check the program contents by pressing PROG on the remote control. The programed tracks are shown in the programed order. On the remote control ONLY: To modify the program 1 Load a CD. • If the current playing source is not the CD player, press CD 3/8, then 7 before going to the next step.
Playing at Random — Random Play Prohibiting Disc Ejection — Tray Lock The tracks will play in no particular order when you use this mode. You can lock the disc tray and prohibit to eject the CD. • This is possible only while the unit is turned on. On the remote control ONLY: On the unit ONLY: To use Random play mode, press RANDOM before or during playing. The RANDOM indicator lights up on the display. RANDOM To prohibit disc ejection, press (STANDBY/ON) while holding 7.
Playing Back Tapes You can play back type I, type II, and type IV tapes without changing any settings. Playing Back a Tape To stop playing, press 7. To fast-wind to the left or to the right, press ¢ or 4 while the tape is not running. The tape direction indicator (3 or 2) starts flashing quickly on the display. To remove the cassette, press 0 for cassette deck. 1 Press 0 for cassette deck.
Recording Continued Recording on a Tape IMPORTANT: • It should be noted that it may be unlawful to re-record pre-recorded tapes, records, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or cable programme and in any literary, dramatic, musical, or artistic embodied therein. • The recording level is automatically set correctly, so it is not affected by the VOLUME, AHB (Active Hyper Bass) PRO, and SOUND MODE settings.
CD Direct Recording One Track Recording Everything on the CD goes onto the tape in the order it is on the CD, or according to the order you have made for Program play. This recording method is convenient when you record tracks while playing a CD. You can only record your favorite songs on the tape. On the unit ONLY: On the unit ONLY: 1 Put a recordable cassette in with the exposed 1 Put a recordable cassette in with the exposed part of the tape down. part of the tape down.
Using the Timers Continued 2 Set the on-time you want the There are three timers available — Daily Timer, Recording Timer, and Sleep Timer. unit to turn on at. 1) Press ¢ or 4 to set the hour, then press TIMER. 2) Press ¢ or 4 to set the minute, then press TIMER. The unit enters off-time setting mode. (Example: PM 1:30) Before using the timers, you need to set the clock built in the unit (see page 9).
6 Press TIMER to complete the timer Using Sleep Timer TIMER setting. With Sleep Timer, you can fall asleep to music. You can set Sleep Timer when the unit is turned on. 7 Press (STANDBY/ON) to turn off the unit (on standby) if you have set the timer with the unit turned on. How Sleep Timer actually works STANDBY/ON The unit automatically turns off after the specified time length passes.
Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service. Symptom No sound is heard. Cause Action • Connections are incorrect or loose. • Check all connections and make corrections. (See pages 6 to 8.) • Disconnect the headphones. • Headphones are connected.
Maintenance To get the best performance of the unit, keep your discs, tapes, and mechanism clean. Handling discs Cleaning the unit • Remove the disc from its case by holding it at the edge while pressing the center hole lightly. • Do not touch the shiny surface of the disc, or bend the disc. • Put the disc back in its case after use to prevent warping. • Be careful not to scratch the surface of the disc when placing it back in its case.
Specifications Design and specifications are subject to change without notice. FS-P5 (CA-FSP5 and SP-UXP5) Amplifier Cassette deck Output Power Frequency response Normal (type I): Wow and flutter 50 W per channel, min. RMS, driven into 6 Ω at 1 kHz with no more than 10 % total harmonic distortion. Audio input sensitivity/Impedance (at 1 kHz) AUX: 400 mV/48 kΩ Audio output level AUX: 260 mV/5.
Authorized Service Centers ® QUALITY SERVICE HOW TO LOCATE YOUR JVC SERVICE CENTER TOLL FREE: 1 (800) 537-5722 http://www.jvc.com Dear Customer, In order to receive the most satisfaction from your purchase,please read the instruction booklet before operating the unit.In the event that repairs are necessary, please call 1 (800)537-5722 for your nearest authorized servicer or visit our website at www.JVC.com Remember to retain your Bill of Sale for Warranty Service.
LIMITED WARRANTY AUDIO-1 JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date of original retail purchase for the period as shown below. ("The Warranty Period") PARTS 1 LABOR YR 1 YR THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.
