AC Adapter (AP-V20U)
Item Details
Power supply AC 110 V to 240 V, 50 Hz/60 Hz
Output DC 11 V, 1.0 A
Allowable operating
temperature
0°C to 40°C (32°F to 104°F)
(10°C to 35°C (50°F to 95°F) during charging)
Dimensions (mm) 78 x 34 x 46 (3-1/8” x 1-3/8” x 1-13/16”) (W x H x
D: excluding cord and AC plug)
Mass Approx. 100 g (0.22 lbs)
Battery Pack (BN-VF815U)
Item Details
Power voltage 7.2 V
Capacity 1460 mAh
Dimensions (mm) 30.5 x 32.5 x 52 (1-1/4” x 1-5/16” x 2-1/8”) (W x H
x D)
Mass Approx. 85 g (0.19 lbs)
Remote Control (RM-V760U)
Item Details
Power supply DC 3 V (button battery CR2025)
Battery life Approx. 1 year (depending on frequency of use)
Operating distance Approx. 5 m (facing up)
Allowable operating
temperature
0°C to 40°C (32°F to 104°F)
Dimensions (mm) 32.5 x 15.6 x 68 (1-5/16” x 5/8” x 2-3/4”) (W x H x
D)
Mass Approx. 16 g (0.04 lbs) (including battery pack)
“Optional Accessories” (A p. 26)
Memo :
0
The specifications and appearance of this product are subject to changes
for further improvement without prior notice.
