EN83
Indications Function
Displays the battery remaining power.
Remaining power level: high
Remaining power level: exhausted
As the battery power comes close to nil, the battery indicator blinks.
When the battery power is exhausted, power turns off automatically.
Appears when no tape is loaded. ( pg. 12)
Appears when the erase protection tab is set to “SAVE” while the Power
Switch is set to “ ” or “ ” and the VIDEO/DSC Switch (GR-DVL810A/
DVL710A/DVL610A/DVL610SH only) is set to “VIDEO”.( pg. 12)
Appears if dirt is detected on the heads during recording. Use an optional
cleaning cassette. ( pg. 86)
Appears if condensation occurs. When this indication is displayed, wait
more than 1 hour until condensation disappears.
Appears if a tape is not loaded when the Recording Start/Stop Button or
SNAPSHOT Button is pressed while the Power Switch is set to “ ” or
“ ” and the VIDEO/DSC Switch (GR-DVL810A/DVL710A/DVL610A/
DVL610SH only) is set to “VIDEO”.
Appears when the tape ends during recording or playback. ( pg. 71)
Appears if a tape in another format is loaded.
● Appears when the date/time is not set. ( pg. 11)
● Appears when the built-in clock battery runs out and the previously set
date/time is erased. Consult your nearest JVC dealer for replacement.
Appears for 5 seconds after power is turned on if the lens cap is attached.
Appears if Audio Dubbing is attempted on a blank portion of a tape.
( pg. 66)
● Appears if Audio Dubbing is attempted on a tape recorded in the LP
mode. ( pg. 66)
● Appears if Audio Dubbing is attempted on a tape recorded in 16-bit
audio. ( pg. 66)
● Appears if A. DUB (e) on the remote control is pressed when the erase
protection tab is set to “SAVE”.( pg. 66)
Warning Indications
TAPE!
TAPE END
SET DATE/TIME!
CHECK TAPE’S ERASE
PROTECTION TAB
HEAD CLEANING
REQUIRED USE
CLEANING CASSETTE
CONDENSATION
OPERATION PAUSED
PLEASE WAIT
DIFFERENT
FORMATTED TAPE
A. DUB ERROR!
<CANNOT DUB
ON A LP RECORDED
TAPE>
<CANNOT DUB
ON A 16BIT
RECORDING>
<CHECK TAPE’S ERASE
PROTECTION TAB>
A. DUB ERROR!
CONTINUED ON NEXT PAGE
LENS CAP
